Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR

Place of Origin : Guangdong, China

Brand Name : Aidecoolr

Model Number : CC2507

Packaging Details : Bulk packaging,polybag packaging

Supply Ability : 3000000 Piece/Pieces per Month

MOQ : 500

Price : $1.70/pieces 1000-1999 pieces

Type : Axial Flow Fan

Applicable Industries : VR, Projector, Laptop, Enviromental Tester

Customized support : OEM, ODM

Electric Current Type : DC

Mounting : mounting by screws

Blade Material : Plastic

Voltage : 5V, 12V, 3.3V

Warranty : 1 Year

After-sales Service Provided : Free spare parts

Noise level : 21~30dBA

Size : 25x25x07mm

Bearing Type : Sleeve Bearing

Port : Shenzhen,Hongkong

Contact Now



Aidecoolr 25x25x7mm DC Small fan,suitable for VR &Environmental Tester & Micro-projector

Noise is another factor to consider when choosing a 3D printer cooling fan. While some noise is to be expected from any fan, excessively loud fans can be distracting and annoying, especially during long print jobs. Some fans are designed to be quieter than others, while others may come with additional noise-reducing features such as anti-vibration mounts.



The large diameter conical fan blade has a remarkable heat dissipation effect, and the strong wind makes your product run stably



Bottom noise persistence



High precision double ball bearing structure, reduce friction resistance, effectively reduce noise, make the product lasting silent



Prevent moisture and moisture

he special waterproof layer can effectively prevent moisture and moisture, and the products can operate normally under bad conditions



energy-efficient

Compact structure, low calorific value, low power loss, improve motor speed and running performance



progress steadily



The blade is balanced by high precision balancing machine, and the running process is smooth and noise-free



sturdy and durable



Internal diameter and ball bearing error is small, precision core with automatic pressing machine pressing, long service life of the fan











Parts Specs:

   P&Q Curve


Bearing type:Sleeve


Material:
Frame & Impeler:PBT

Lead wire:
UL1061 AWG #28 or equivalent
Red Wire Positive (+)
Black Wire Negative (-)

FG,PWM,RD,Protection functions are optional



3.3V,5V,12V,24V are available


   Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR







Parameters:




Model
Bearing
Type
Rated
Voltage
operation
Voltage
Current
Input Power
Speed
Air Flow
static Pressure
Noise Level
voc vDc Amp Watt RPM CFM MM-Ho dBA
cC2507LO5s Sleeve 5v 4.5~5.5 0.09 0.45 8,000±10% 1.30 1.80 21.0
cc2507M05s Sleeve 5v 4.5~5.5 0.10 0.50 10,000±10% 1.70 3.50 25.0
cC2507H05s Sleeve   4.5-5.5 0.15 0.75 12,000±10% 2.10 4.80 30.0
cC2507L12S sleeve   10.8~13.2 0.04 0.48 8,000±10% 1.60 1.80 21.0
cc2507M12s Sleeve 12V 10.8~13.2 0.07 0.84 10,000主10% 1.70 3.50 25.0
cC2507H12S Sleeve     0.10 1.20 12,000±10%   4.80 30.0





Electrical  Specifications:

 Insulation Resistance  10MΩ/between unshackled wire and frame at 500VDC/min
 Dielectric Strength  5Ma Max./Measured between lead wire(+)and frame at 500VAC/min
 Rotating Direction  Anti-Clockwise
 Polarity Protect  Circuit is protected when VCC&GND are exchanged
 No. of pole  4Poles





Environmental Specifications

 Operating Temp  Range  Temperature:-10℃~+70℃
 Humidity:35%~85%RH
 Store Temperature  Temperature:-40℃~+70℃
 Humidity:35%~85%RH
 Thermal Shock  Standard:MIL-STD 202F Method 107D,Condition D
 Insulation Shock  UL:Class A

Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR

Application:

 Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR

















Packaging & Shipping
FCL Shipment   LCL Shipment
Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR   Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR





 Air shipment:

Stable Small 5V DC 3D Printer Cooling Fan 3.3V 25x25x7mm For VR



FAQ

 Lifetime:

 Bearing type  Lifetime
 Sleeve  30,000 hours
 Hydraulic  40,000 hours
 2-Ball  60,000 hours
